Product Specifications

• RATING
  40 KVA | 60 KVA | 80 KVA | 100 KVA | 120 KVA | 160 KVA | 200 KVA | 250 KVA | 300 KVA
• Input Voltage Range
  ((380 VAC/400VAC /415 VAC) ± 15% 3 phase 4 wire(3 + N + PE) (or any Voltage range as per requirement)
• Input Frequency Range
  50/60 Hz ±10%
• Output Voltage Range
  380/400/415 VAC 3 Phase + Neutral + Ground
• Output Frequency
  50/60 Hz ± 0.1%
• Overload capacity

  105 ~110% for 1 Hour

  110 ~125% for 10 min
